FIRERAY Heater Keeps Optical Beam Smoke Detectors Clear of Condensation

FIRERAY optical beam smoke detectors provide wide area smoke detection when it is impractical to use traditional point-type detectors.

They are also ideal for large indoor spaces with high ceilings, such as warehouses, sports arenas, factories or shopping malls.

There are two general types of detector: projected, which utilise two detector heads; and reflective, which have one detector head and a reflector (prism).

With the onset of autumn, lower temperatures can cause condensation to form on detector lenses and reflective prisms.

This obscures the lens and prism, reducing the amount of infrared (IR) light reaching the detector. This has a similar effect to smoke and can lead to unwanted false alarms.

To combat this issue, Fire Fighting Enterprises (FFE) has developed a new range of anti-condensation heaters for its FIRERAY range of optical beam smoke detectors and reflective prisms.

The detector heater circulates a current of warm air over the lens, raising its ambient temperature by up to 10°C and maintaining the lens at an incrementally higher temperature than the surrounding air.

This dramatically reduces the likelihood of condensation forming on the lens which, in turn, reduces the potential for false alarms.

The prism heater is an ultra-slim heating pad which is fixed behind the mounting plate.

As with the detector heater, it maintains the temperature of the prism above that of the surrounding air, preventing condensation from occurring and reducing false alarms.

As well as being an ideal solution to the problem of seasonal cold weather, the heaters could also be used year-round on detectors and prisms located in temperature-controlled cold storage areas.

Heaters are available for use with the FIRERAY 3000, FIRERAY 5000 and FIRERAY 50R/100R smoke detector ranges.

They are highly practical tools for reducing the environmental impact of condensation and minimising false alarms.

About Fire Fighting Enterprises

Fire Fighting Enterprises is at the forefront of beam-type optical smoke detection technology, leading the market in providing fire extinguishers for aviation use, and also producing a range of vibration switches for industrial applications.

Fire Fighting Enterprises is a Halma Company.
